Overview

Learn the basics of modifying our core blocks and creating your own from scratch

What makes a block?

A block type is made up of three components:

  1. A PHP code snippet to render the block content in the frontend
  2. A block blueprint which tells Kirby which fields should be available in the block
  3. An (optional) Panel preview for the WYSIWYG experience

You can find the source files for the existing block types in the documentation for each block type.

With this knowledge, we can go ahead and either modify existing block types or create new ones.

Extending core blocks

You can customize all existing block types to your needs in one or all of the following ways:

  1. Change how the block renders in the frontend by overwriting the snippet for the block
  2. Add or replace fields in a block type by overwriting the Blueprint file for the block type. This will often go hand in hand with modifying the output as in point 1.
  3. Change how the block looks in the Panel by overwriting its preview.

To modify a block, you can use the standard blueprints, snippets, and previews of each block type as a basis for your changes. Read more…

Example: extending the heading block

Let's take the heading block and add a simple text field to add a custom ID for the heading

fields:
  blocks:
    type: blocks
    fieldsets:
      heading:
        extends: blocks/heading
        fields:
          customId:
            label: Custom ID
            type: text

This will add the customID field below the default fields of the block.

Extending existing fields in a block type

Instead of only adding new fields, you can also adjust the field settings for the default fields of the block.

Let's limit the number of heading levels for our heading block.

fields:
  blocks:
    type: blocks
    fieldsets:
      heading:
        extends: blocks/heading
        fields:
          level:
            options:
              - h2
              - h3

You can find all block fields and their settings in the docs for each block.

Adding tabs

You can extend our core blocks with additional tabs. Be aware though that you need to recreate all default fields in this case, as tabs will replace the default fields.

fields:
  blocks:
    type: blocks
    fieldsets:
      heading:
        extends: blocks/heading
        tabs:
          content:
            fields:
              level:
                type: select
                empty: false
                default: "h2"
                width: 1/6
                options:
                  - h1
                  - h2
                  - h3
              text:
                type: writer
                inline: true
                width: 5/6
              customId:
                label: Custom ID
                type: text
          styles:
            fields:
              backgroundColor:
                type: select
                options:
                  - red
                  - green
                  - blue
              textColor:
                type: select
                options:
                  - white
                  - black

Block snippets

The HTML for each individual block is stored in its own block snippet. All our default block types bring their own snippets and can be overwritten. Block snippets are stored in /site/snippets/blocks

As an example, if you want to overwrite the snippet for our heading block, you would create a snippet file called /site/snippets/blocks/heading.php

The default heading snippet

<<?= $level = $block->level()->or('h2') ?>>
    <?= $block->text() ?>
</<?= $level ?>>

Your customized version

/site/snippets/blocks/heading.php
<<?= $level = $block->level()->or('h2') ?> id="<?= $block->customId()->or($block->id()) ?>">
    <?= $block->text() ?>
</<?= $level ?>>

Custom block types

You create custom block types from the same three components. If you don't need a visual preview, you even make do with only a blueprint and a snippet. Learn how to create your own custom block types with our extensive documentation.

Custom blocks can be defined directly in the fieldsets list (however, if you want to use a block in multiple places, it's better to create it in a plugin, see below):

fields:
  blocks:
    type: blocks
    fieldsets:
      - heading
      - text
      button:
        name: Button
        icon: bolt
        fields:
          link:
            type: url
          text:
            type: text

In the example above, we mix the default block types (heading and text) with our own custom block type to add a call to action button.

Preview

Custom block types don't have a visual preview by default. They show up with the icon and the name from your blueprint definition.

Label

Custom block types can use the label property to show some information from a field in the block. This can be particularly useful for blocks that don't have a preview:

fields:
  blocks:
    type: blocks
    fieldsets:
      - heading
      - text
      button:
        name: Button
        icon: bolt
        label: "{{ text }}"
        fields:
          link:
            type: url
          text:
            type: text

Within the label property, you have access to an array of field properties, here are some more examples:

label: "{{ structure.length }}" # to get the number of items in a structure field

label: "{{ gallery.length }} images" # to get the number of images in a gallery files field

label: "{{ image.0.filename }}" # to get the filename of the first image in the image files field

Editing

To edit a custom block type, editors can either double-tap on the block or click on the edit icon in the toolbar. The block drawer opens with the fields you've defined for the block.

Drawer-less blocks

If you don't define any fields, the block won't have a drawer. This can be useful for blocks that don't feature any configuration (e.g. the default line block).

Tabs

You can also define tabs for your blocks when they have a lot of settings:

fields:
  blocks:
    label: Text
    type: blocks
    fieldsets:
      - heading
      - text
      button:
        name: Button
        icon: bolt
        tabs:
          content:
            fields:
              link:
                type: url
              text:
                type: text
          styles:
            fields:
              class:
                type: text
              id:
                type: text

The tabs will then show up in the block drawer.

Global block types

For reuse in multiple places, custom block type definitions can be stored in a folder called site/blueprints/blocks. In this case we would store it in /site/blueprints/blocks/button.yml:

# /site/blueprints/blocks/button.yml
name: Button
icon: bolt
tabs:
  content:
    fields:
      link:
        type: url
      text:
        type: text
  styles:
    fields:
      class:
        type: text
      id:
        type: text

Now, we can use it in our fieldsets option for any blocks field.

fields:
  blocks:
    type: blocks
    fieldsets:
      - heading
      - text
      - button

This also works in groups:

fields:
  text:
    type: blocks
    fieldsets:
      text:
        label: Text
        type: group
        fieldsets:
          - heading
          - text
          - list
          - button
      media:
        label: Media
        type: group
        fieldsets:
          - image
          - video
      code:
        label: Code
        type: group
        fieldsets:
          - code
          - markdown

Custom block type snippet

To render the HTML for your custom block type in the frontend, create a snippet in /site/snippets/blocks. In this case we create a file called /site/snippets/blocks/button.php

/site/snippets/blocks/button.php
<a href="<?= $block->link() ?>" class="btn">
  <?= $block->text() ?>
</a>

Preview plugins

You can turn your custom blocks into highly visual, interactive representations with a custom block preview plugin.

Read our plugin guide on how to create such previews.
